F85 EFI Outboard Motor

F85 is based on the same block as the F115. Parsun 85HP 4-stroke outboard motor is equipped with electronic fuel injection, which does not require a battery and provides excellent fuel economy, easy start, slower trolling speed, quick throttle response, lower emission and very smooth rides on the water.

Category: 4-Stroke Outboards

Previous Product Next Product

FEATURES

● Fuel-water separator and fuel filter prevent any debris or water in the fuel from getting into the engine.
● Built-in freshwater flushing system provides easy routine flushing.
● High output 18 amp alternator for battery charging and fishing electronics.
● Multi point electronic fuel injection with ECM control delivers the precise fuel / air mixture for optimum combustion and provides smooth running.
● Warning & protection: Several different sensors continually monitor the critical engine's major functions. They will send out special signals to inform you in advance, such as over-revving, overheating, start-in-gear protection for safe engine starting, safety lanyard or low oil pressure, and automatically reduce the engine power to prevent damage.
1. Equipped with a reliable Delphi E.F.I. system and multifunction diagnostic scanner (scanner available as option), the outboard motor ensures high quality, long life and easily maintenance, while reducing your fuel and maintenance costs.
2. Through propeller hub exhaust and long shaft provides a smooth quiet operation.
3. Long-term durability of critical engine components: water cooling fuel system, stainless steel water pump housing liner and camshaft-driven engine oil pump ensure the outstanding durability.
4.Large displacement and single overhead cam increase the low-end power with smooth and strong performance, and help the operator get excellent acceleration even when pushing a heavy load.

SPECIFICATIONS

Model	F85
Specs Options	F85BEL-T/F85FEX-T
Transom Height	20/25in.
Weight	179Kg/185Kg
Full Throttle Operating Range	5300～6300r/min
Maximum Putput	62.5kW（85HP）@5600r/min
Idling Speed	800～900 r/min
Engine Type	L4 SOHC 16 Valve
Displacement	1832 cc
Bore*Stroke	81.0×88.9 mm
Ignition System	TCI
Control System	Tiller/Remote
Start System	Electric start
Gear Positions	F-N-R
Gear Ratio	2.15
Trim And Tilt System	Electric
Fuel Tank Capacity	External
Max. Fuel Consumption	30.5L/h
Engine Oil Capacity	3L
Gear Oil Capacity	760cc
Propeller Potions	3-15"in or 3-17"in
Specs Options description: 1. The propeller shall be selected according to the size and purpose of the boat; 2. F in front of 90 means "four-stroke". B=Back control ( Tiller ) F=Front control E= Electric start L= Long shift

Our F85 models are perfect for aluminum fishing boats, bay boats, inflatable boats, pontoon boats and fishing boats. They are designed to satisfy the demand of leisure boaters with all kinds of boats. Parsun 100HP EFI outboard motors are powerful, reliable and easy to operate.
